How to Install Cabinet Handles: A Step-by-Step Guide

Installing cabinet handles is a straightforward DIY project, but accurate measuring and drilling are essential. A small placement error can leave handles crooked, uneven, or difficult to align across multiple cabinet doors and drawers.

The basic process is to choose the handle position, measure and mark the mounting holes, use a cabinet hardware jig or template for consistent placement, drill the holes carefully, and secure the handle with the correct screws.

Before drilling, also check whether you are installing new hardware or replacing existing handles. Replacement handles may need to match the center-to-center spacing of the existing holes, while new cabinet doors and drawer fronts give you more flexibility with placement.

In this guide, we’ll show you how to install cabinet handles step by step, including the tools you need, how to measure handle spacing, where to place hardware on doors and drawers, how to drill clean mounting holes, and how to avoid common installation mistakes.

1. Tools and Hardware You Need

Before installing cabinet handles, gather the tools and hardware you need. Having everything ready makes it easier to keep handle placement consistent across multiple doors and drawers.

For most cabinet handle installations, you may need:

• Tape measure
• Pencil
• Cabinet hardware jig or template
• Drill/driver
• Sharp drill bit sized for the mounting screws
• Screwdriver
• Level or small square
• Painter’s tape
• Clamps, if needed
• Cabinet handles or pulls
• Mounting screws in the correct length

If you are still choosing the color or finish of your knobs and pulls, our cabinet hardware finishes guide explains common options and how they pair with different cabinet styles.

Why a Cabinet Hardware Jig Helps

A cabinet hardware jig or template is especially useful when installing handles on several doors or drawers. Once the jig is set to the correct position, you can repeat the same hole placement without measuring each cabinet front from scratch.

Before drilling, test the jig on the first cabinet and confirm that the handle position looks correct and is comfortable to use.

Check the Mounting Screws Before You Drill

Do not assume that the screws included with the handles will fit every cabinet door or drawer front.

Check the thickness of the cabinet front and make sure the mounting screws are long enough to pass through the material and securely engage the handle without being excessively long.

If you are replacing existing handles, also measure the distance between the existing screw holes before buying new hardware. This measurement is commonly referred to as the center-to-center spacing.

2. Measure Handle Spacing Before Drilling

Before marking or drilling any holes, confirm the size and mounting pattern of the cabinet hardware.

This is especially important for pulls and handles that use two mounting screws.

Measure Center-to-Center Spacing

For a two-screw cabinet pull, center-to-center spacing is the distance from the center of one mounting hole to the center of the other.

Common cabinet pulls are available in many different center-to-center sizes, so do not choose a replacement handle based on overall length alone.

If you are replacing existing hardware, measure the existing holes carefully before ordering new pulls.

A new pull with the same center-to-center spacing can usually use the existing holes, while a different spacing may require drilling new holes or repairing the old ones.

Knobs vs. Pulls

Cabinet knobs typically use one mounting screw, so placement is based on a single hole.

Cabinet pulls usually require two mounting holes, which means both the position and spacing must be accurate.

Before drilling for a pull:

• Confirm the center-to-center measurement.
• Check the overall handle size.
• Make sure the handle fits comfortably on the door or drawer front.
• Verify that the mounting screws are the correct length.

Check Existing Holes Before Replacing Hardware

If you are replacing old cabinet handles, remove one existing handle first and inspect the holes.

Check whether:

• The holes are still clean and secure.
• The new handle matches the existing spacing.
• The old holes are visible outside the new hardware.
• The drawer or door material around the holes is damaged.

If the new handle does not match the existing hole spacing, decide whether you want to repair the old holes before drilling new ones rather than forcing the new hardware into the original positions.

Test One Handle Before Drilling the Rest

Before drilling multiple cabinet doors or drawers, mark and test the position on one cabinet first.

Hold the handle in place or use painter’s tape to preview the location.

Check that the handle:

• Looks centered and balanced.
• Is comfortable to reach.
• Does not interfere with neighboring doors or drawers.
• Matches the placement planned for the rest of the kitchen.

Once the first position is confirmed, use the same measurements or jig settings for the remaining cabinet fronts.

3. Where to Place Cabinet Handles on Doors and Drawers

Handle placement affects both how the cabinets look and how comfortable they are to use. Before drilling, choose one consistent placement rule and apply it across similar cabinet doors and drawers.

Cabinet Door Handle Placement

On cabinet doors, knobs and pulls are usually installed near the edge opposite the hinges so they are easy to reach.

For Shaker-style cabinet doors, the rails and stiles provide useful visual reference points.

If you are working with Shaker cabinetry, see our Shaker cabinet guide for a closer look at Shaker door construction, styles, and design options.

Common placement approaches include:

• Centering a knob near the corner where the rail and stile meet
• Aligning the end of a pull with the rail
• Centering the pull vertically along the stile
• Keeping the same distance from the door edge across all matching cabinet doors

The exact position can vary depending on the hardware size and cabinet design, but consistency is more important than using one fixed measurement for every kitchen.

Upper vs. Base Cabinet Doors

For upper cabinets, hardware is typically positioned near the lower corner of the door.

For base cabinets, handles are usually placed near the upper corner.

This keeps the hardware within comfortable reach and creates a consistent visual pattern across the kitchen.

Before drilling, hold the handle in place and check that it does not interfere with neighboring doors, trim, or adjacent hardware.

Drawer Handle Placement

On most drawer fronts, handles are installed horizontally and centered from left to right.

For a standard drawer, center the knob or pull vertically on the drawer front unless the cabinet design calls for another position.

For tall drawer fronts, you may prefer to position the hardware slightly above the vertical center for easier reach, but keep the placement consistent across similar drawers.

Wide Drawers

A wide drawer may use one longer pull or, depending on the design, two smaller pulls.

Before drilling two sets of holes, check the drawer width, hardware size, and visual balance carefully.

If using two pulls, position them symmetrically so the spacing is equal on both sides.

Mark the First Door or Drawer Before Repeating the Layout

Do not drill every cabinet front immediately.

Mark the first door or drawer, hold the hardware in position, and step back to check how it looks with the surrounding cabinetry.

Once the placement is confirmed, transfer the same measurements to the remaining cabinets using a jig or template.

4. How to Install Cabinet Handles Step by Step

Once you have confirmed the handle size, spacing, and placement, you can begin drilling and installing the hardware.

Work on one cabinet door or drawer first. After confirming that the first handle is positioned correctly, repeat the same measurements or jig settings across the remaining cabinets.

Step 1: Mark the Handle Position

Use a tape measure, pencil, square, or cabinet hardware jig to mark the mounting location.

For a knob, mark the center of the single mounting hole.

For a pull, mark both mounting holes according to the handle’s center-to-center spacing.

Double-check the measurements before drilling.

If you are working on a finished cabinet surface, painter’s tape can make pencil marks easier to see and help protect the area while you mark the holes.

Step 2: Set Up the Cabinet Hardware Jig

If you are installing several handles, set the jig or template to the position you confirmed earlier.

Place it firmly against the edge of the cabinet door or drawer front and make sure it sits square before marking or drilling.

For repeated installations, keep the jig setting unchanged unless the door or drawer size changes.

Step 3: Drill the Mounting Holes

Use a sharp drill bit that is appropriate for the mounting screw and cabinet material. If you are unsure whether your cabinet door is solid wood, MDF, HDF, thermofoil, laminate, or another material, review our guide to cabinet door materials and finishes before drilling.

Keep the drill as straight and perpendicular to the cabinet surface as possible so the screw passes through cleanly and the handle sits flat.

Drill slowly and avoid forcing the bit through the material.

When possible, support the back of the drilling area with a scrap wood block to help reduce tear-out as the drill bit exits the cabinet front.

Step 4: Insert the Mounting Screws

Insert the mounting screws from the inside of the cabinet door or drawer front and thread them into the handle.

Start both screws by hand before fully tightening a two-screw pull. This gives you a little room to align the hardware before it is secured.

Check that the screw length is appropriate for the cabinet front.

Drawer installations may require longer screws if the fastener must pass through both the drawer box and a separate drawer front.

Step 5: Tighten and Align the Handle

Hold the handle in its final position while tightening the mounting screws.

Tighten until the hardware is secure, but do not overtighten. Excessive force can damage the cabinet material, strip the screw threads, or leave marks around the mounting holes.

For pulls, check that the handle is straight before completing the final tightening.

Step 6: Check the First Installation

Before drilling the rest of the cabinets, step back and inspect the first handle.

Check that:

• The handle is straight.
• The placement looks balanced.
• The hardware is comfortable to reach.
• The screws are secure.
• The handle does not interfere with nearby doors or drawers.

If everything looks correct, use the same measurements or jig settings for the remaining cabinet hardware.

Step 7: Repeat Consistently

Install the remaining handles one at a time.

Periodically compare neighboring doors and drawers instead of waiting until the entire kitchen is finished.

Small placement differences are much easier to correct before all of the holes have been drilled.

5. How to Replace Cabinet Handles Using Existing Holes

Replacing cabinet handles is usually easier than installing hardware on a new cabinet because the mounting holes are already drilled. The key is making sure the new hardware matches the existing hole spacing.

Remove the Existing Handle

Open the cabinet door or drawer and loosen the mounting screws from the inside.

Support the handle with your other hand while removing the screws so it does not fall and damage the cabinet finish.

Once the handle is removed, inspect the existing mounting holes for damage, chipping, or loose material.

Measure the Existing Hole Spacing

For a two-screw pull, measure the center-to-center distance between the existing mounting holes.

Use this measurement when choosing the replacement hardware.

Do not rely only on the overall length of the old handle. Two pulls can look similar in size while using different mounting-hole spacing.

If the replacement pull matches the existing center-to-center measurement, you can usually reuse the original holes.

Test the New Handle Before Tightening

Insert the screws through the existing holes and loosely attach the new handle.

Before fully tightening it, confirm that:

• Both screws enter the handle smoothly.
• The new hardware covers the existing holes.
• The handle sits flat against the cabinet surface.
• The handle is straight.
• No old marks or damage remain visible around the hardware.

Once the position looks correct, tighten the screws until the handle is secure.

What If the New Handle Does Not Match the Existing Holes?

If the new hardware uses a different center-to-center spacing, do not force the screws into the existing holes.

You may need to:

• Choose a replacement handle with matching hole spacing.
• Repair the existing holes before drilling new ones.
• Use a backplate that covers the previous holes, if appropriate for the cabinet style.
• Refinish the damaged area before installing different hardware.

If the cabinet door or drawer front is painted or finished, filling and refinishing old holes may remain visible unless the repair is carefully matched.

If the cabinet door is cracked, chipped, or damaged around the hardware mounting area, check our cabinet door repair guide before drilling additional holes.

For that reason, choosing replacement hardware with the same center-to-center spacing is often the simplest option.

Check All Cabinets Before Ordering Replacement Hardware

Before purchasing new handles for an entire kitchen, remove and measure a few existing pulls from different doors and drawers.

Confirm that the same spacing is used throughout the cabinetry.

Older kitchens or previously remodeled cabinets may contain more than one hardware size, so checking first can prevent ordering the wrong replacement pulls.

6. Common Mistakes When Installing Cabinet Handles

Cabinet hardware installation is simple once the measurements are correct, but a small drilling or placement mistake can be difficult to hide afterward. Avoid these common problems before installing the rest of your handles.

Check Your Work as You Go

Do not wait until every handle has been installed before checking alignment.

After every few doors or drawers:

• Step back and compare the hardware visually.
• Check that neighboring handles are level.
• Make sure drawer pulls remain centered.
• Confirm that screws stay secure.
• Check that doors and drawers open without hardware interference.

If you notice a placement problem, stop and correct the jig or measurements before drilling additional holes.

7. FAQ About Installing Cabinet Handles

What size drill bit should I use for cabinet handles?

Use a drill bit that matches the diameter required for the mounting screw and hardware.

The hole should allow the screw to pass through cleanly without being excessively loose. Check the handle manufacturer’s instructions and test the drill bit on scrap material when possible before drilling the cabinet door or drawer front.

Where should cabinet handles be placed?

On cabinet doors, hardware is typically installed near the edge opposite the hinges.

Upper cabinet handles are commonly positioned near the lower corner of the door, while base cabinet handles are usually placed near the upper corner.

Drawer pulls are commonly installed horizontally and centered from left to right.

The exact position can vary depending on the cabinet style and hardware size, but consistent placement across similar doors and drawers is important.

How do I measure cabinet pull spacing?

For a pull that uses two mounting screws, measure from the center of one mounting hole to the center of the other.

This is called the center-to-center spacing.

If you are replacing existing hardware, use this measurement to find a new pull that matches the original holes.

Can I replace cabinet handles without drilling new holes?

Yes, if the new handle uses the same mounting-hole spacing as the existing hardware.

Remove one old handle and measure the center-to-center distance between the holes before purchasing replacements.

If the new pull uses different spacing, you may need to repair the old holes and drill new ones.

Should drawer pulls be centered?

For most standard drawer fronts, pulls are installed horizontally and centered from left to right.

The vertical position can vary depending on the drawer size and cabinet design.

For taller drawer fronts, some homeowners position the pull slightly above the vertical center for easier reach. Whatever placement you choose, keep it consistent across similar drawers.

How do I keep cabinet handles aligned?

Use a cabinet hardware jig or template after confirming the placement of the first handle.

Keep the jig settings consistent across matching doors and drawers, and check the hardware visually every few installations.

Do not drill all of the cabinet fronts before confirming that the first handle looks straight and properly positioned.

Final Thoughts

Installing cabinet handles is a manageable DIY project when the measuring and drilling are done carefully. Confirm the handle placement and center-to-center spacing first, test one door or drawer before drilling the rest, and use a cabinet hardware jig or template to keep the installation consistent.

Take your time when drilling, use the correct screw length, and check the alignment as you work. A few extra minutes spent measuring and testing the first handle can prevent uneven hardware and unnecessary holes across the rest of the kitchen.

If cabinet hardware installation is part of a larger DIY kitchen project, see our Cabinet Installation 101 guide for additional guidance on cabinet preparation, leveling, fastening, and installation.

If you are still planning your kitchen, explore our kitchen cabinets to compare available cabinet styles, finishes, sizes, and configurations.
